Technical Features
RS-400/600/700 (Sliding Plate Type) uses PLC system and Human-machine interface, combined with Ultra-high preci-sion rotary encoder to locate and infrared device, uses in-verter to control left-right feeding, adjusts the speed according to the stone material. It uses hydraulic lifting system Main spare parts adopt imported good-quality materials Thus the whole machine is featured with high cutting eff-ciency, high cutting precision, high stability, easy-operating to suit granite and marble with high value and big size.
| Product name | Unit | RS-400 | RS-600 | RS-700 |
| /Blade diameter | mm | 400 | 600 | 700 |
| Max working dimensions(LxWxH) | m | 3.2x2.0x1.8 | 3.2x2.0x1.9 | 3.2x2.0x2.4 |
| Size of worktable | m | 3.2x2.0 | ||
| Worktabl titing degree | n° | 0°~85° | ||
| Worktabl rotation range | n° | 0°~90°/0°~360(Positioning every 45 °) | ||
| Wate consumption | m3/h | 3.5 | 3.5 | 4 |
| Main motor power | kw | 15 | 18.5 | 18.5 |
| Total power | Kw | 21 | 24 | 24 |
| Weight | Kg | 6400 | 6600 | 7000 |
| Oveiall dimensions(LxWxH) | m | 6.0x4.7×3.1 | 6.0x4.7x3.1 | 6.0x4.7x3.3 |
