Diesel screw air compressors are vital to the success of mining operations. Stone mining, in particular, requires a high level of efficiency and reliability from the equipment. Our diesel screw air compressors are specifically designed for the stone mining industry, ensuring that operations run smoothly and efficiently.
Our compressors feature powerful diesel engines with advanced technologies that make them highly durable and robust. They are capable of providing a continuous and reliable source of compressed air, which is essential in the stone mining process. With a range of customizable options, we guarantee that our compressors will meet the unique needs of your stone mining operation.
In addition, our diesel screw air compressors are easy to operate and maintain. The innovative design of our compressors ensures that they are highly efficient and require minimal downtime for maintenance.
If you are looking for reliable and efficient equipment for your stone mining operation, look no further than our diesel screw air compressors.
| Air displacement | 14.2m³/min | Rated exhaust pressure | 0.7mpa | |
| Maximum exhaust pressure | 0.8mpa | Motor Power | 75kw | |
| Overall dimension | 2160*1220*1580mm | Nominal speed | 2970r/min | |
| Weight | 1550kg | Voltage | 380v |
Factory direct sales, providing one-stop stone mining equipment and factory equipment, one-stop service
Screw Compressor works in the following way:
Ambient air is drawn through the intake filter and the multifunctional control system into the screw compressor block. This block consists of a pair of screw rotors. The main rotor, driven by an electric motor, takes the secondary rotor with it. The air is drawn in by the rotation of both of the interlocking rotors and is continually compressed. During rotation, coolant is injected into the rotors and forms a hydrostatic film between the main and secondary rotors. The function of the coolant is to seal the rotors, lubricate the bearings and adsorb the compression heat. Before compressed air leaves the compressor ( at 80 ºC approx.) it is separated from the coolant before being cooled in the aftercooler to approx.. 8ºC to 12ºC above the ambient temperature. The coolant then passes to the thermostatic control block and filter, before entering the cooler where it is cooled from approx.. 80ºC down to 50ºC. It is then injected back into the screw compressor block.
Features:
Direct drive via flexible coupling.
Fully encapsulated screw compressor block.
User friendly service access.
Top quality, washable, oil resistant sound insulation.
Ready for operation, prewired and fully enclosed.
With operating mode selector switch Automatic-Off-Continuous.
Centrally mounted cooling fan provided for compressed air and lubricant coolers.
Diesel screw air compressors are vital to the success of mining operations. Stone mining, in particular, requires a high level of efficiency and reliability from the equipment. Our diesel screw air compressors are specifically designed for the stone mining industry, ensuring that operations run smoothly and efficiently.
Our compressors feature powerful diesel engines with advanced technologies that make them highly durable and robust. They are capable of providing a continuous and reliable source of compressed air, which is essential in the stone mining process. With a range of customizable options, we guarantee that our compressors will meet the unique needs of your stone mining operation.
In addition, our diesel screw air compressors are easy to operate and maintain. The innovative design of our compressors ensures that they are highly efficient and require minimal downtime for maintenance.
If you are looking for reliable and efficient equipment for your stone mining operation, look no further than our diesel screw air compressors.
| Air displacement | 14.2m³/min | Rated exhaust pressure | 0.7mpa | |
| Maximum exhaust pressure | 0.8mpa | Motor Power | 75kw | |
| Overall dimension | 2160*1220*1580mm | Nominal speed | 2970r/min | |
| Weight | 1550kg | Voltage | 380v |
Factory direct sales, providing one-stop stone mining equipment and factory equipment, one-stop service
Screw Compressor works in the following way:
Ambient air is drawn through the intake filter and the multifunctional control system into the screw compressor block. This block consists of a pair of screw rotors. The main rotor, driven by an electric motor, takes the secondary rotor with it. The air is drawn in by the rotation of both of the interlocking rotors and is continually compressed. During rotation, coolant is injected into the rotors and forms a hydrostatic film between the main and secondary rotors. The function of the coolant is to seal the rotors, lubricate the bearings and adsorb the compression heat. Before compressed air leaves the compressor ( at 80 ºC approx.) it is separated from the coolant before being cooled in the aftercooler to approx.. 8ºC to 12ºC above the ambient temperature. The coolant then passes to the thermostatic control block and filter, before entering the cooler where it is cooled from approx.. 80ºC down to 50ºC. It is then injected back into the screw compressor block.
Features:
Direct drive via flexible coupling.
Fully encapsulated screw compressor block.
User friendly service access.
Top quality, washable, oil resistant sound insulation.
Ready for operation, prewired and fully enclosed.
With operating mode selector switch Automatic-Off-Continuous.
Centrally mounted cooling fan provided for compressed air and lubricant coolers.
