The best-combined mining method at present:
Granite Mining Machine and diamond wire saw machine combined mining.
Granite Mining Machine Cost lower
To save resources, a diamond wire saw is used to cut the horizontal bottom surface of the stone instead of manual rock drilling, wedge splitting, and separation of the horizontal surface of the stone, forming a new method of full sawing and mining of granite.
Using a diamond wire saw machine to cut the horizontal bottom surface of the stone, instead of manual wedge splitting and separation, this method is extended to granite and marble mining, which is very suitable for the mining of granite and marble mines with complete ore bodies, few cracks, uniform color, and small changes. Mines in Hubei Xianfeng, Xinjiang Shanshan, Hunan Huaihua, and other places have been very successful.
Granite Mining Machine Cost low cost and high efficiency
1. Use a Granite Mining Machine to cut vertically on the separated body according to the specifications of the rough material and cut it into long strips of stone.
2. Diamond wire saw cuts the horizontal bottom surface.
3. Use a rock drill to drill and split the long strips of stone into blocks.
Granite Mining Machine Cost
All those who want to save costs and improve efficiency should first develop a mining plan
| Product name | Unit | RS-1360/1960ZL/M | RS-1500/2100ZL/M | RS-1950/2550ZL/M | RS-2600/3200ZL/M |
| Diameter of driving wheel | mm | Φ3600 | Φ3800 | Φ4800 | Φ4800 |
| Cutting width | mm | 1360-1960 | 1500-2100 | 1950-2550 | 2600-3200 |
| Max cutting depth | mm | 1550 | 1650 | 2150 | 2150 |
| Main motor power | kw | 55 | 55 | 65 | 65 |
| Water consumption | m/n | 5 | 5 | 5 | 5 |
| Total power | kw | 131.2 | 131.2 | 137 | 137 |
| Dimension of external form | mm | 4080x1560x2600 | 4280x1700x2700 | 5210x2110x3370 | 5210x2760x3370 |
| Total weight | kg | 8000 | 8200 | 11500 | 13000 |
The best-combined mining method at present:
Granite Mining Machine and diamond wire saw machine combined mining.
Granite Mining Machine Cost lower
To save resources, a diamond wire saw is used to cut the horizontal bottom surface of the stone instead of manual rock drilling, wedge splitting, and separation of the horizontal surface of the stone, forming a new method of full sawing and mining of granite.
Using a diamond wire saw machine to cut the horizontal bottom surface of the stone, instead of manual wedge splitting and separation, this method is extended to granite and marble mining, which is very suitable for the mining of granite and marble mines with complete ore bodies, few cracks, uniform color, and small changes. Mines in Hubei Xianfeng, Xinjiang Shanshan, Hunan Huaihua, and other places have been very successful.
Granite Mining Machine Cost low cost and high efficiency
1. Use a Granite Mining Machine to cut vertically on the separated body according to the specifications of the rough material and cut it into long strips of stone.
2. Diamond wire saw cuts the horizontal bottom surface.
3. Use a rock drill to drill and split the long strips of stone into blocks.
Granite Mining Machine Cost
All those who want to save costs and improve efficiency should first develop a mining plan
| Product name | Unit | RS-1360/1960ZL/M | RS-1500/2100ZL/M | RS-1950/2550ZL/M | RS-2600/3200ZL/M |
| Diameter of driving wheel | mm | Φ3600 | Φ3800 | Φ4800 | Φ4800 |
| Cutting width | mm | 1360-1960 | 1500-2100 | 1950-2550 | 2600-3200 |
| Max cutting depth | mm | 1550 | 1650 | 2150 | 2150 |
| Main motor power | kw | 55 | 55 | 65 | 65 |
| Water consumption | m/n | 5 | 5 | 5 | 5 |
| Total power | kw | 131.2 | 131.2 | 137 | 137 |
| Dimension of external form | mm | 4080x1560x2600 | 4280x1700x2700 | 5210x2110x3370 | 5210x2760x3370 |
| Total weight | kg | 8000 | 8200 | 11500 | 13000 |
